1 – DJI BS100 Intelligent Battery Station.
Original price was: $1,800.00.$1,199.00Current price is: $1,199.00.
Description
The DJI Matrice 400 BS100 Intelligent Battery Station enables fast, intelligent charging for up to three TB100 batteries and two WB37 batteries. It offers multiple charging modes, including Rapid Mode, which delivers a full charge in just 45 minutes at 220V.
Seamlessly integrated with DJI’s intelligent battery management system, the BS100 allows for real-time status monitoring, automatic discharging, and convenient firmware updates through the remote controller.
| Model | BS100 |
| Net Weight | 11.8 kg (26 lbs) |
| Dimensions | 605 × 410 × 250 mm (L × W × H) |
| Supported Batteries | TB100 / TB100C Intelligent Flight Battery, WB37 Battery |
| Operating Temperature | –4 °F to 104 °F (–20 °C to 40 °C) |
| Input | 100–240 V AC, 50–60 Hz, 10 A |
| Output Power | TB100 Interface: • 100–110 V AC → ≈ 1185 W • 110–180 V AC → ≈ 1474 W • 180–240 V AC → ≈ 2184 W WB37 Interface: ≈ 52 W USB-C: 5 V 3 A, 9 V 3 A, 12 V 3 A, 15 V 3 A, 20 V 3.25 A |
| Charging Channels | 3 × TB100 / TB100C • 2 × WB37 (sequential) |
| Charging Modes | Ready-to-Fly 90 % • Standard 100 % • Fast • Silent |
| Charging Time* | TB100/TB100C 0 % → 100 %: • 45 min (220 V, Fast) • 70 min (110 V, Fast) • 110 min (Silent) |
*Tested at 25 °C (77 °F).
